SOUND SUPPRESSED HYDRAULIC BREAKERS

The NEW Sound Suppressed Takeuchi range of hydraulic breakers are specifically designed to match the hydraulic flows of the complete range of Takeuchi mini excavators from 1 to 15 tonnes.

High performance breakers designed specifically for tool carrier weight loads with a rugged design to match the tough break-out environments.

TKB COMPACT BREAKERS

• TKB 52 Slim-line (0.8 - 1.8 t)

• TKB 72 Slim-line ( 1.3-2.7t)

• TKB 52-S Silenced (1.0 - 1.8 t)

• TKB 72-S Silenced (1.3 - 2.7 t)

• TKB 102-S Silenced (2.0 - 4.0 t)

• TKB 302-S Silenced (3.4 - 8.0 t)

• TKB 402-S Silenced (4.6 - 9.0 t)

• TKB 802-S Silenced (7.0 - 15 t)

The range offers significantly quieter breaker performance, the casing helps minimize dBA sound levels, designed for all types of working environments including quiet zones. A solid all round case suppresses sound within the cast steel protective body. the solid casing offers enhanced protection of vulnerable areas, sealing against dust and debris.

The 6 models offer excellent power to weight ratios.

More durable, more serviceable and more easily maintained. The breaker body consists of fewer integral component parts and no tie rods, an integrated accumulator and single lower tool bushing - a simplified breaker with fewer component problems for improved serviceability.

The breakers have an easy attach pivot connection block for hoses, provides for varying positions of auxiliary ports on the carrier.
PDF BROCHURE

• TKB-52

• TKB-72

• TKB52-S

• TKB72-S

• TKB102-S

• TKB302-S

• TKB402-S

• TKB802-S
